供應德國isabellenhuette電阻
Type Picture Description Design Power Tolerance TCR Resistance (min) Resistance (max) Download
銷售isabellenhuette電阻A-H A-H 4-terminal resistor with low TCR. Low resistance values ??for high accuracy.** Installed on heat sink 4618,3825 (metrisch) 10** W 0.1 * 30 ppm/K 0.001 ? 100 ? Download
AZ-H AZ-H 4-terminal resistor with very low TCR. Low resistance values ??for high accuracy. ** Installed on heat sink 4618,3825 (metrisch) 10** W 0.1 * 3 ppm/K 0.002 ? 1 ? Download
PBH PBH 2-terminal resistor in space-saving design similar to TO 247. ** Installed on heat sink TO-247 (ähnlich) 10** W 0.5 * 50 ppm/K 0.002 ? 100 ? Download
PBV PBV 4-terminal resistor in space-saving design. ** Installed on heat sink 2317 (metrisch) 10** W 0.5 * 30 ppm/K 0.0005 ? 1 ? Download
PBV-Z PBV-Z 4-terminal resistor in space-saving design. ** Installed on heat sink 2317 (metrisch) 10** W 1 * 5 ppm/K 0.003 ? 10 ?
PSB PSB 2-terminal resistor in space-saving design similar to TO-247. ** Installed on heat sink TO-247 (ähnlich) 10** W 1 * 50 ppm/K
Type Picture Description Tolerance TCR Resistance (min) Resistance (max) Download
IKL-F IKL-F Plug-in calibration resistor for the measurement of currents up to 200 A. *** Only with factory calibration certificate in own DAkkS calibration labaratory possible 0.05 * 10 ppm/K 0.001 ? 1 ? Download
IKL-G IKL-G Plug-in calibration resistor for the measurement of currents up to 200 A. *** Only with factory calibration certificate in own DAkkS calibration laboratory possible 0.05 * 10 ppm/K 0.0001 ? 0.001 ? Download
銷售isabellenhuette電阻A-H A-H 4-terminal resistor with low TCR. Low resistance values ??for high accuracy.** Installed on heat sink 4618,3825 (metrisch) 10** W 0.1 * 30 ppm/K 0.001 ? 100 ? Download
AZ-H AZ-H 4-terminal resistor with very low TCR. Low resistance values ??for high accuracy. ** Installed on heat sink 4618,3825 (metrisch) 10** W 0.1 * 3 ppm/K 0.002 ? 1 ? Download
PBH PBH 2-terminal resistor in space-saving design similar to TO 247. ** Installed on heat sink TO-247 (ähnlich) 10** W 0.5 * 50 ppm/K 0.002 ? 100 ? Download
PBV PBV 4-terminal resistor in space-saving design. ** Installed on heat sink 2317 (metrisch) 10** W 0.5 * 30 ppm/K 0.0005 ? 1 ? Download
PBV-Z PBV-Z 4-terminal resistor in space-saving design. ** Installed on heat sink 2317 (metrisch) 10** W 1 * 5 ppm/K 0.003 ? 10 ?
PSB PSB 2-terminal resistor in space-saving design similar to TO-247. ** Installed on heat sink TO-247 (ähnlich) 10** W 1 * 50 ppm/K
Type Picture Description Tolerance TCR Resistance (min) Resistance (max) Download
IKL-F IKL-F Plug-in calibration resistor for the measurement of currents up to 200 A. *** Only with factory calibration certificate in own DAkkS calibration labaratory possible 0.05 * 10 ppm/K 0.001 ? 1 ? Download
IKL-G IKL-G Plug-in calibration resistor for the measurement of currents up to 200 A. *** Only with factory calibration certificate in own DAkkS calibration laboratory possible 0.05 * 10 ppm/K 0.0001 ? 0.001 ? Download
